Precision Mold Repair Fiber Laser Welding Machine

  • Precision Mold Repair Fiber Laser Welding Machine
  • Precision Mold Repair Fiber Laser Welding Machine
Precision Mold Repair Fiber Laser Welding MachinePrecision Mold Repair Fiber Laser Welding Machine

Precision Mold Repair Fiber Laser Welding Machine

Precision Mold Repair Fiber Laser Welding Machine

Application: available for kitchen hardware, metal sheet, mold repair, precise instruments and auto parts, etc. It is specially ideal for large plastic injection mold/tool/die mold maintenance and repair welding. Microscope is available for observing system.

Attention: Base on HWPM series, HWPRO Series' laser head is designed to rotate 360 degree, its worktable is electrically lifted and moved by using precision ball screw and high straight guide rail, which is lighter and more flexible with accurate positioning and can bear up to 100Kgs for large mold.

Model

HWPM200

HWPM400

HWPM1500

HWPRO1500

Max. laser power

200W

400W

1500W

1500W

Rated power

8KW

12KW

7KW

7KW

Supply voltage

220V

380V

220V

220V

Laser frequency

1~20Hz

1~30Hz

1~30Hz

1~30Hz

Spot range

0.2~2mm

0.3~3mm

0.1~5mm

0.1~5mm

Cooling system

1.5P

3P

1.5P

1.5P

Laser wavelength

1064nm

1064nm

1080(±10)nm

1080(±10)nm

Pulse width

0.1~10MS

0.1~10MS

1~80MS

1~80MS

Observing system

Microscope

Weight / Package volume

Pallet 1: 160X136X70cm / 210Kgs

Pallet 2: 135X80X70cm / 150Kgs

Total: 360Kgs / 2.30CBM

(subject to actual configuration)

Pallet 1: 150X65X105cm / 225Kgs

Pallet 2: 190X90X90cm / 205Kgs

Total: 430Kgs / 2.60CBM

(subject to actual configuration)
